60ah
Feature
1. Safety Performance: safest Lithium Iron Phosphate battery, CE IEC UN38.3 approved, built-in BMS
2. Long Cycle Life: > 4000 times, 6-8 times life cycle compare to lead acid battery
3. Deep cycle, no memory effect, highly efficient
4. Compact size and light weight: 1/2 size & weight of lead acid battery
5. Good performance at high temperature
6. Low self-discharge rate: < 3% month
Model | 24V | |
Battery Type | LiFe PO4 | |
Battery Module | TY-24-150 | TY-24-200 |
Battery Capacity (Ah) | 150AH | 200AH |
Nominal Battery Energy (kWh) | 3.6 | 4.8 |
Nominal Voltage (V) | 25.6V | 25.6V |
Nominal Output Current (A) | 75 | 100 |
Weight (Kg) | 29.8 | 36 |
Dimension (L*W*H mm) | 430*210*210 | 430*290*210 |
Package Dimension (L*W*H mm) | 470*250*250 | 470*330*330 |
Working Voltage (V) | 22.4~2.9.2 | 44.8~58.4 |
Operating Temp.Range (°C) | -20~50 | |
Calendar Life (Cycles) | 6000@25°C,80%DOD | |
Protection Level | IP54 | |
Terminal | Anderson Or Other | |
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |
Monitoring & Protection | BMS | |
| Display | LCD | |
Q1: What products do you offer?
Our main products is Lithium Ion Batteries. Now we can offer Home Energy Storage, Telecom Battery， Battery Pack，Lithium Battery 24V 48V etc.
Q2: How can I get a sample to check your quality?
If you need sample to test, please pay for the freight and sample cost. And the sample cost will be returned back to you after you place an bulk order more than our MOQ.
Q3: Can I have the products with my own logo?
Yes. We can offer both OEM and ODM service with prototype design and small MOQ.
Q4: How long can I expect to get the sample?
The samples will be ready for delivery in 3~5days after we receive the payment.
Q5:Can you give me a discount?
Yes, based on wholesale service, we have better discount for bigger quantities. We will quote you the best price based on your order quantity.
Q6. What are the advantages that distinguish from others?
1. Official cooperative supplier of China State Grid Official
2. With professional product development team
3. Rich experience in wireless computer room
4. With superior energy storage solution
