150ah
1.Super long cycle life
Over 4000 cycles at 80%DOD can be circularly used.
2.Fast charge capability
Very fast charging capability up to 50A.
3.Low self discharge
<1% per month at 25°C.
4. Long Life
10 years design life at 25°C.
5.Green environmental material
Eco-friendly and nonpolluting, no acids or no hazardous and noxious substances (including lead, cadmium, mercury).
6. Can be used Max 4 in series or Max 4 in parallel
7.In compliance with standard
UN/NOT 38.3, CE.
8. High safety & stable performance
No explosion and no fire under collision. No risk of leakage
9.Completely maintenance-free
Completely Maintenance-free throughout battery lifetime saves OPEX for the users.
10.Intelligent Integrated Battery Manage System(BMS)
Built-in BMS automatically protects internal cells from over-charge, over-discharge, over-temperature, short-circuit, etc. Ensure battery safety and reliability. Equalize and balance each cell. Prolong battery life. SOC-DOD-SOH reporting/setting device events, battery parameters, and storage, intelligent monitor, remote measure, remote communication, remote control.
Model | 12V | ||
Battery Type | LiFe PO4 | ||
Battery Module | TY-12-100 | TY-12-150 | TY-12-200 |
Battery Capacity (Ah) | 100 AH | 150AH | 200AH |
Nominal Battery Energy (kWh) | 1.2 | 1.8 | 2.4 |
Nominal Voltage (V) | 12.8V | ||
Nominal Output Current (A) | 50 | 75 | 100 |
Weight (Kg) | 12.16 | 15.5 | 18.9 |
Dimension (L*W*H mm) | 270*170*230 | 240*205*190 | 270*180*230 |
Package Dimension (L*W*H mm) | 310*210*270 | 280*245*230 | 310*220*280 |
Working Voltage (V) | 11.2-14.6 | ||
Operating Temp.Range (°C) | -20~50 | ||
Calendar Life (Cycles) | 6000@25°C,80%DOD | ||
Protection Level | IP54 | ||
Terminal | Anderson Or Other | ||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | ||
Monitoring & Protection | BMS | ||
