150ah
Benefit From Our Advantages
Backed by professional supporting team, we have expertise in R&D, OEM production and marketing. With the support of a professional and dedicated engineering and operation team, we are available to bringing customers' idea into reality. Flexible to customized request, such as sound adjusted, color, package, and accessories adjusted, so you can enjoy our quick one-stop OEM service.
Model | 12V | ||
Battery Type | LiFe PO4 | ||
Battery Module | TY-12-100 | TY-12-150 | TY-12-200 |
Battery Capacity (Ah) | 100 AH | 150AH | 200AH |
Nominal Battery Energy (kWh) | 1.2 | 1.8 | 2.4 |
Nominal Voltage (V) | 12.8V | ||
Nominal Output Current (A) | 50 | 75 | 100 |
Weight (Kg) | 12.16 | 15.5 | 18.9 |
Dimension (L*W*H mm) | 270*170*230 | 240*205*190 | 270*180*230 |
Package Dimension (L*W*H mm) | 310*210*270 | 280*245*230 | 310*220*280 |
Working Voltage (V) | 11.2-14.6 | ||
Operating Temp.Range (°C) | -20~50 | ||
Calendar Life (Cycles) | 6000@25°C,80%DOD | ||
Protection Level | IP54 | ||
Terminal | Anderson Or Other | ||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | ||
Monitoring & Protection | BMS | ||
Benefit From Our Advantages
Backed by professional supporting team, we have expertise in R&D, OEM production and marketing. With the support of a professional and dedicated engineering and operation team, we are available to bringing customers' idea into reality. Flexible to customized request, such as sound adjusted, color, package, and accessories adjusted, so you can enjoy our quick one-stop OEM service.
Model | 12V | ||
Battery Type | LiFe PO4 | ||
Battery Module | TY-12-100 | TY-12-150 | TY-12-200 |
Battery Capacity (Ah) | 100 AH | 150AH | 200AH |
Nominal Battery Energy (kWh) | 1.2 | 1.8 | 2.4 |
Nominal Voltage (V) | 12.8V | ||
Nominal Output Current (A) | 50 | 75 | 100 |
Weight (Kg) | 12.16 | 15.5 | 18.9 |
Dimension (L*W*H mm) | 270*170*230 | 240*205*190 | 270*180*230 |
Package Dimension (L*W*H mm) | 310*210*270 | 280*245*230 | 310*220*280 |
Working Voltage (V) | 11.2-14.6 | ||
Operating Temp.Range (°C) | -20~50 | ||
Calendar Life (Cycles) | 6000@25°C,80%DOD | ||
Protection Level | IP54 | ||
Terminal | Anderson Or Other | ||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | ||
Monitoring & Protection | BMS | ||
