200ah
Applications:
Electric Propelling Applications
♦ Engine Starting Battery
♦ Commercial Bus and Transit:
E-car, E-bus, Golf troller/car, E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan, Wheel chair,
E-truck, E-sweeper, Floor cleaner, E-walker etc.
♦ Intellectual Robots
♦ Power tools: electric drills, toys
Energy Storage
♦ Solar-Wind Power System
♦ City Grid (On/Off)
Back-up System and UPS
♦ Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment
Features:
* Long service life.
* Low self-discharge.
* Environment friendly.
* Good safety performance.
* Maintenance-free operation.
*Broad operating temperature range.
Model | 24V | |
Battery Type | LiFe PO4 | |
Battery Module | TY-24-150 | TY-24-200 |
Battery Capacity (Ah) | 150AH | 200AH |
Nominal Battery Energy (kWh) | 3.6 | 4.8 |
Nominal Voltage (V) | 25.6V | 25.6V |
Nominal Output Current (A) | 75 | 100 |
Weight (Kg) | 29.8 | 36 |
Dimension (L*W*H mm) | 430*210*210 | 430*290*210 |
Package Dimension (L*W*H mm) | 470*250*250 | 470*330*330 |
Working Voltage (V) | 22.4~2.9.2 | 44.8~58.4 |
Operating Temp.Range (°C) | -20~50 | |
Calendar Life (Cycles) | 6000@25°C,80%DOD | |
Protection Level | IP54 | |
Terminal | Anderson Or Other | |
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |
Monitoring & Protection | BMS | |
| Display | LCD | |
