100ah
Terli
1. High energy density
2. Low internal resistance
Methods of reducing the internal resistance:
**Using carbon coated aluminum foil
**Multiple electrode tab design
**Increasing the width of electrode tab
**Coating PVDF on battery separator
**Pore-creating artificially
3.Long lifespan
Usable for more than 4,000 charge-discharge cycles
> 4 times than lead acid battery
> 2 times than li ion battery
4.Excellent performance in high and low temprature
Usable in extremely cold and hot environments (-20 to 60 ºC)
Model | 48V |
Battery Type | LiFe PO4 |
Battery Module | TY-48-200 |
Battery Capacity (Ah) | 200AH |
Nominal Battery Energy (kWh) | 9.6 |
Nominal Voltage (V) | 51.2V |
Nominal Output Current (A) | 100 |
Weight (Kg) | 72 |
Dimension (L*W*H mm) | 580*370*230 |
Package Dimension (L*W*H mm) | 620*410*270 |
Working Voltage (V) | 44.8~58.4 |
Operating Temp.Range (°C) | -20~50 |
Calendar Life (Cycles) | 6000@25°C,80%DOD |
Protection Level | IP54 |
Terminal | Anderson Or Other |
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited |
Monitoring & Protection | BMS |
| Display | LCD |
