1.Wide operating temperature
2.Safe Lithium Ion Technology
3.High energy density and conversion efficiency
4.High charge & discharge currents
5.Ultra-high cycling performance
Model | Power Pack | |||
Battery Type | LiFe PO4 | |||
Battery Module | 3kWh | 5kWh | 7kWh | 10kWh |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power（kW） | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight（Kg） | 40 | 53 | 70 | 83 |
Dimension (L*W*H mm) | 500*530*240 | |||
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
| Communication | CAN/RS485 | |||
| Performance Warranty | 10 Years | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
