1.High quality BMS (Battery Management System) :We use Mult-functional 100A continuous BMS with built-in IC compatible with military standards for over-current, over-discharge, over-charge, short-circuit, adverse-polarity connection, balancing functions.
The has 3-folds of over current protection:(1) continuous discharge current of 100A ;(2) 125A protection for 30s;(3) 400A for 3-5 s protection.
And the MOSFET and IC, the most important parts of BMS, are all quality brand.
2.Automatic Welding , quality assembly materials and exquisite workmanship: the battery packs are spot welded by automatic welder (please check attached pictures) for high accuracy and minimized energy consumption; and all the welding materials including nickle tabs and wires can resist high current; our worked are trained for skills and expertise.
3.Strict QC standards: we have strict QC procedure and standards to keep the failure rates under 0.2%.
Model | 12V | ||
Battery Type | LiFe PO4 | ||
Battery Module | TY-12-100 | TY-12-150 | TY-12-200 |
Battery Capacity (Ah) | 100 AH | 150AH | 200AH |
Nominal Battery Energy (kWh) | 1.2 | 1.8 | 2.4 |
Nominal Voltage (V) | 12.8V | ||
Nominal Output Current (A) | 50 | 75 | 100 |
Weight (Kg) | 12.16 | 15.5 | 18.9 |
Dimension (L*W*H mm) | 270*170*230 | 240*205*190 | 270*180*230 |
Package Dimension (L*W*H mm) | 310*210*270 | 280*245*230 | 310*220*280 |
Working Voltage (V) | 11.2-14.6 | ||
Operating Temp.Range (°C) | -20~50 | ||
Calendar Life (Cycles) | 6000@25°C,80%DOD | ||
Protection Level | IP54 | ||
Terminal | Anderson Or Other | ||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | ||
Monitoring & Protection | BMS | ||
