Main Features:
Terli brand factory: The most advanced battery can ensure a longer service life and excellent discharge performance. We have a professional R&D team and are committed to providing customers with perfect power solutions.
Unparalleled portability: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate battery is only 1/3 the weight of lead acid, so when considering towing or mobility, it is an unquestionable choice for RV, marine and off-grid applications.
Longer service life: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate battery can provide 2500-7000 cycles and a 10-year lifespan, while a typical lead-acid chemical process can provide 200-500 cycles and a 3-year lifespan.
High efficiency power: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate batterycan maintain a capacity above 12V, and can use up to 95% of the capacity. Compared with the operation, the utilization rate of the lead-acid battery is only 50%, which can greatly improve the operation time .
Comprehensive protection: The unique built-in battery management system (BMS) of the lithium battery protects it from overcharge, deep discharge, overload, overheating and short circuit, and low self-discharge rate, thus ensuring maintenance-free for up to 1 year storage. The built-in low temperature cut-off function prevents charging at temperatures below 23°F (-5°C).
Model | Telecom Battery | |||
Battery Type | LiFe PO4 | |||
Battery Module | 3kWh | Helios 5 | Helios 7 | Helios 10 |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power(kW) | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight(Kg) | 40 | 53 | 70 | 83 |
Dimension (L*W*H mm ) | 19inch 4U | 19inch 4U | 19inch 4U | 19inch 4U |
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
Communication | CAN/RS485 | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
HMI | LCD/Touch Screen |
