Cautions:
1.Use special caution when working with Li-ion cells, they are very sensitive to charging characteristics and may explode if mishandled;
2. Make sure user has enough knowledge on Li-ion rechargeable batteries in
Charging, discharging and assembly before use;
3. We are not responsible for any damage caused by misuse or mishandling of these Li-ion batteries;
4. Strongly suggest that you use our smart Li-ion battery charger to recharge
The battery pack;
5. Never use conventional DC adapter to charge the battery module.
Model | 48V |
Battery Type | LiFe PO4 |
Battery Module | TY-48-200 |
Battery Capacity (Ah) | 200AH |
Nominal Battery Energy (kWh) | 9.6 |
Nominal Voltage (V) | 51.2V |
Nominal Output Current (A) | 100 |
Weight (Kg) | 72 |
Dimension (L*W*H mm) | 580*370*230 |
Package Dimension (L*W*H mm) | 620*410*270 |
Working Voltage (V) | 44.8~58.4 |
Operating Temp.Range (°C) | -20~50 |
Calendar Life (Cycles) | 6000@25°C,80%DOD |
Protection Level | IP54 |
Terminal | Anderson Or Other |
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited |
Monitoring & Protection | BMS |
| Display | LCD |
